Shear Beam Load Cell (2TONS)
Specifications:
- Rated Output (mV/V): 3.00±0.015
- Nonlinearity: ±0.02%FS
- Hysteresis: ±0.02%FS
- Repeatability: ±0.01%FS
- Creep (30 minutes): ±0.02%FS
- Zero Balance: ±1.00%FS
- Temperature Effect on Zero: ±0.02%FS/10°C
- Temperature Effect on Output: ±0.02%FS/10°C
- Input Resistance: 385±5Ω
- Output Resistance: 350±3Ω
- Insulation Resistance: ≥5000MΩ
- Excitation Voltage: 10V(DC/AC)
- Compensated Temperature Range: -10°C ~ 50°C
- Operating Temperature Range: -20°C ~ 60°C
- Safe Overload: 120%FS
- Cable: 5.4×6 m
